CHEMGUARD® - NFF 3x3 UL201

Chemguard® NFF 3x3 UL201 is a next-generation, alcohol-resistant non-fluorinated foam concentrate engineered for rapid knockdown and superior burnback resistance on Class B hydrocarbon and polar solvent fuel fires. UL162 listed and designed in accordance with NFPA Standard 11, this synthetic foam concentrate provides effective fire and vapor suppression at a 3% application rate for both hydrocarbon and polar solvent fuels.

Unlike traditional AR-AFFF products, NFF 3x3 UL201 contains no intentionally added PFAS chemistry, inherently complying with European directives (EU 2017/1000 on PFOA and EU POPs Directive 2019/1021) — making it an environmentally responsible choice without sacrificing performance

Key Features & Benefits

• PFAS-Free Fire Protection – Non-fluorinated formulation for environmentally safer firefighting.

• UL162 Listed Performance – Matches control times of traditional AR-AFFF agents at 0.10 gpm/ft² (4.1 Lpm/m²) for spill fires.

• Exceptional Burnback Resistance – Extended drain times produce a longer-lasting foam blanket for improved post-extinguishment vapor suppression.

• Alcohol-Resistant Barrier – On polar solvent fires, the foam forms a protective polymeric membrane to suppress vapors and seal the fuel surface.

• Cooling Action – High water content enhances cooling for faster fire suppression.

Applications

Ideal for municipal and industrial emergency response where both hydrocarbon and polar solvent fuels are present, including:

• Industrial chemical and petroleum processing facilities

• Truck/rail loading and unloading terminals

• Flammable liquid containment areas

• Mobile firefighting equipment

NFF 3x3 UL201 may also be combined with dry chemical agents for even greater firefighting performance

Performance & Proportioning

• Recommended operational range: 35 °F to 120 °F (2 °C to 49 °C)

• Proportioning: Works with most conventional in-line proportioning equipment (balanced pressure pump proportioners, bladder tanks, venturi-type proportioners, and handline nozzles with fixed eductor/pick-up tubes)

• Foam characteristics (EN 1568-3: 2008):

  • Expansion Ratio > 7:1 (fresh water), > 6:1 (salt water)

  • 25% Drain Time > 40 min (fresh water)

  • 50% Drain Time > 60 min (fresh water)

Ordering Information

• 5 gal (19 L) pail – Part No. 453050 (45 lb / 20.4 kg)

• 55 gal (208 L) drum – Part No. 453052 (495 lb / 224.5 kg)

• 265 gal (1,003 L) tote – Part No. 453054 (2,463 lb / 1,117 kg)

Why Choose Chemguard® NFF 3x3 UL201 from IPS?

IPS proudly supplies Chemguard® NFF 3x3 UL201 to organizations needing high-performance, non-fluorinatedfirefighting foam solutions. This product delivers exceptional Class B fire control while reducing environmental impact — a powerful choice for modern fire suppression.
